Tampers
Compact soil quick and effectively
Powerful
Maximum power to quickly compact all types of soils, including clay.
Durable
Heat-treated cylinder and chromeplated piston for excellent durability.
Performance
Well-balanced, smooth-operating tool which is easily guided by one person.
Our tampers
Many tampers on the market are designed for sand ramming only and therefore lack the full power necessary for contracting operations. CP 0003 is well equipped to handle light to medium contracting applications while CP 0004 is designed for heavier contracting jobs. They are both light-weight, well balanced and easy to use first class compaction tools. The butt is secured to the lower end of the piston rod. A valve in the back head assembly controls the reciprocating movement of the piston. The hand valve (trigger) controls the air flow.
Users
Trenching companies, General contractors, Municipalities, Gas and water boards, Cable layers, Utilities, Local authorities
Applications
Used in construction, landscaping, renovation and other applications to compact soil around foundations and structures and to compact backfill in trenches.
| PNEUMATIC TAMPERS |
|
CP 0003 |
CP 0004 |
| Weight |
kg |
13.5 |
19 |
| Length |
mm |
1,320 |
1,270 |
| Butt Size |
mm |
127 |
1.588 |
| Body Diamater |
mm |
22.2 |
25.4 |
| Blows Per Minute |
bpm |
800 |
780 |
| Air Consumption |
l/s |
8.4 |
13 |
| Air Inlet |
|
1/2" NPTF |
1/2" NPTF |
| Valve Type |
|
Simplate |
Ring |
Vibration Level 3 Axes
(ISO 20643) |
m/s² |
32.3 |
44.8 |
Sound Power Level
Guaranteed (2000/14/EC) |
dB(A) |
108 |
109 |
Sound Pressure Level
(ISO 11203) |
dB(A) |
95 |
94 |
| Part Number |
|
T019307 |
T022292 |
|
|
